CCTV / IP Cameras

AV1115DN
1,3 megapixel day/night IP camera

New MegaVideo Compact series 1,3 Megapixel IP Camera
42 fps @ 1280(H) x 1024(V)
Color mode: 0.1 lux @ F1.4
CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

AV3115DN
3 megapixel day/night IP camera

New MegaVideo Compact series 3 Megapixel IP Camera
21 fps @ 2048(H) x 1536(V)
Color mode: 0,1 lux in extended exposure mode or 0.3 lux @ F1.4
CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

http://www.arecontvision.com

AV3105DN
3 megapixel day/night IP camera

3 Megapixel IP Camera
15 fps @ 2048(H)x1536 (V)
Color mode: 0,1 lux in extended exposure mode or 0.2 lux @ F1.4
1/2” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

AV3155DN
3 megapixel day/night IP vandal-resistant camera

3 Megapixel IP Dome Camera
15 fps @ 2048(H)x1536 (V)
Integrated 4.5-10mm Megapixel Varifocal Lens
Color mode: 0,1 lux in extended exposure mode or 0.2 lux @ F1.4
1/2” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max
IP66 dome housing
Camera gimbal with 360° pan and 90° tilt adjustment

http://www.arecontvision.com

AV3135
3 /1.3 megapixel day/night IP camera

3 Megapixel color and 1.3 Megapixel B/W
15 fps @ 2048x1536, 32 fps @ 1280X1024
0.02 lux @ F1.4
1/2” CMOS Sensors
H.264 (MPEG 4, Part 10)
On-camera motion detection
12V DC, 24V AC, POE
Power consumption: 4 Watts max

AV3125IR
3 megapixel day/night IP camera with IR light

3 Megapixel IP Bullet Camera
21 fps @ 2048(H)x1536 (V)
Integrated 4.5-10mm Megapixel Varifocal Lens
Color mode: 0,3 lux
1/2,5” CMOS Sensor
H.264 (MPEG 4, Part 10)
Motorized IR cut filter
12V DC, 24V AC, POE
48 IR LEDS
IP66 housing with heater and blower
External lens adjustment (Plug-n-play) and Easily adjustable 3-axis bracket

http://www.arecontvision.com

ZN-PT304L
PAN/TILT camera

Live Video and Audio Monitoring via Internet Explorer
4x Digital Zoom
MPEG-4 Video Compression (Simple Profile)
Compact Size with Stylish Design
Easy to Install and Configure
Optimized Synchronization of Audio and Video
Intelligent Motion Detection
Superior Low Light Performance
Excellent Image Quality with Up to 30 Frames Per Second in Full VGA resolution
Free-bundled 16-channel recording software included
Built-in Microphone

MP3A
3 mpx IP camera

3 Megapixel IP Camera
15 fps @ 2048(H)x1536 (V)
0.2 lux @ F1.4
1/2” CMOS Sensor
Motion JPEG
DC Iris
12V DC, 24V AC, POE
Power consumption: 4,5 Watts max

http://www.cbceurope.com/

SNC-CS10

High-quality and affordable network-based camera
1/4-type Progressive Scan CCD
400 TV lines
Maximum frame rate JPEG : 18 fps / MPEG4 : 15 fps (640 x 480), 30 fps (370 x 240)
Number of clients JPEG: 20, MPEG-4: 10
Min. illumination 0.14 lx (F1.0, AGC ON, 30 IRE, Shutter Speed 1/4)
Analogue Composite Video Output
Power consumption 5.4 W max.
Power requirements AC 24 V/DC 12 V
Motion Detection, Pre-/post-alarm recording
Exposure control Auto Iris Lens/Manual Iris Lens

http://www.sonybiz.net

SNC-DH110

X Series compact mini-dome HD (720p) resolution network security camera
1/3.8 type progressive scan "Exmor" CMOS sensor
Minimum illumination: 2.0 lx / AGC(38db)/ 50IRE(IP)
Horizontal viewing angle: 88 degrees, Focal length: f=2.3
Pan angle: Approx. 340°, Tilt angle 0° to 60°
Codec image size (H x V) 1280x960, 1376x768, 1280x800, 1280x720, 1024x768, 1024x576, 768x576, 720x576, 704x576, 800x480, 720x480, 640x480, 640x368, 384x288, 352x288, 320x240, 320x192, 176x144
Video compression format: H.264, MPEG-4, JPEG
Maximum frame rate: MPEG-4 / H.264: 30fps (1280×720)
Number of clients: 5
Power requirements: PoE

SNC-DH210

X Series compact mini-dome HD (1080p) resolution network security camera
1/2.8 type progressive scan "Exmor" CMOS sensor
Minimum illumination: 2.0 lx / AGC(38db)/ 50IRE(IP)
Horizontal viewing angle: 88 degrees, Focal length: f=3.3
Pan angle: Approx. 340°, Tilt angle 0° to 60°
Codec image size (H x V) 2048×1536 (Jpeg Only), 1920x1080, 1600x1200, 1680x1056, 1440x912, 1280x1024, 1280x960, 1376x768, 1280x800, 1280x720, 1024x768, 1024x576, 768x576, 720x576, 704x576, 800x480, 720x480, 640x480, 640x368, 384x288, 352x288, 320x240, 320x192, 176x144
Video compression format: H.264, MPEG-4, JPEG
Maximum frame rate: JPEG:12fps (2048×1536) /15fps(1920×1080) /30fps: (1280×720), MPEG-4 / H.264: 15fps (1920×1080) / 30fps (1280×720)
Number of clients: 5
Power requirements: PoE

http://www.sonybiz.net

SNC-CH140

HD network fixed networkDay/Night camera, utilising state-of-the-art image enhancement with View-DR, and XDNR noise reduction.
1/3" Exmor HD CMOS image sensor with mechanical IRC filter
CS-mount vari focal zoom lens f=2.8 to 8.0 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1280 x 720)
Number of clients: 10
Min. illumination: Day : 0.20 lx, Night : 0.10 lx (F1.2/View-DR OFF/XDNR ONMiddle/ VE OFF/AGC High/50 IRE[IP])
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 9 W max.
Power requirements AC 24 V/DC 12 V/PoE
ONVIF conformance

SNC-DH140

HD network Day/Night mini-dome network camera, utilising state-of-the-art image enhancement with View-DR, and XDNR noise reduction.
1/3" Exmor HD CMOS image sensor with mechanical IRC filter
CS-mount vari focal zoom lens f=3.1 to 8.9 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1280 x 720)
Number of clients: 10
Min. illumination: Day : 0.20 lx, Night : 0.10 lx (F1.2/View-DR OFF/XDNR ONMiddle/ VE OFF/AGC High/50 IRE[IP])
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
DEPA Advanced analytics
Power consumption 8 W max.
Power requirements AC 24 V/DC 12 V/PoE
ONVIF conformance

http://www.sonybiz.net

SNC-DH280

Full HD Network Vandal Resistant Day/Night Minidome Camera with View-DR Technology and IR Illuminator
1/3" Exmor HD CMOS image sensor with mechanical IRC filter
CS-mount vari focal zoom lens f=3.1 to 8.9 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1920 x 1080)
Number of clients: 10
Clearly see objects in the dark up to 15 m away with IR Illuminators, which allow the camera to operate in 0 lx lighting conditions
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
DEPA Advanced analytics
Built-in heater for use in cold
IP66 Rating
Power consumption 23 W max.
Power requirements AC 24 V/DC 12 V/PoE
IR Illuminator: (Wave Length: 850nm (Typical), IR LED: 21pcs)
Operating temperature -30°C to +50°C (with built in heater)
ONVIF conformance

SNC-CH280

Full HD Network Vandal Resistant Day/Night Minidome Camera with View-DR Technology and IR Illuminator
1/3" Exmor HD CMOS image sensor with mechanical IRC filter
CS-mount vari focal zoom lens f=3.1 to 8.9 mm, easy focus function - automatic adjustment of image focusing that simplifies installation
Horizontal resolution 600 TV lines
View-DR enhanced wide Dynamic range technology, XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H.264/MPEG-4/JPEG: 30 fps (1920 x 1080)
Number of clients: 10
Clearly see objects in the dark up to 15 m away with IR Illuminators, which allow the camera to operate in 0 lx lighting conditions
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
Triple-encoding Capability
DEPA Advanced analytics
Built-in heater for use in cold
IP66 Rating
Power consumption 23 W max.
Power requirements AC 24 V/DC 12 V/PoE
IR Illuminator: (Wave Length: 850nm (Typical), IR LED: 21pcs)
Operating temperature -30°C to +50°C
ONVIF conformance

http://www.sonybiz.net

SNC-RH164

HD network Day/Night PTZ dome camera, utilising state-of-the-art image enhancement and XDNR noise reduction.
1/3 HD CMOS image sensor
Focal length f=5.1 to 51mm; 10X zoom ratio
Horizontal resolution 480 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4: 30 fps (1280 x 720); JPEG: 10 fps (1280 x 720)
Number of clients: 10
Min. illumination: Day:2.1 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analogue) Night:0.19 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analogue)
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 82 W max.
Power requirements AC 24 V/DC 12 V/High Power over Ethernet capability - hPOE (IEEE802.3at)
ONVIF conformance
IP66 Rated. Maximum environmental protection for heavy duty outdoor monitoring applications

SNC-RH124

HD network Day/Night PTZ dome camera, utilising state-of-the-art image enhancement and XDNR noise reduction.
1/3 HD CMOS image sensor
Focal length f=5.1 to 51mm; 10X zoom ratio
Horizontal resolution 480 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4: 30 fps (1280 x 720); JPEG: 10 fps (1280 x 720)
Number of clients: 10
Min. illumination: Day:2.1 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analogue) Night:0.19 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP/Analogue)
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 27 W max.
Power requirements AC 24 V/DC 12 V/High Power over Ethernet capability - hPOE (IEEE802.3at)
ONVIF conformance

http://www.sonybiz.net

SNC-RS84P

Outdoor Day/Night PTZ Dome camera, utilising state-of-the-art image enhancement, 18X optical zoom and XDNR noise reduction.
1/4" CCD with Exwave HAD™ technology
Focal length f=4.1 to 73.8mm; 18X zoom ratio
Horizontal resolution 530 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Number of clients: 10
Min. illumination: Day: 0.4 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP) 0.8 lx (Slow Shutter OFF 50 IRE Analogue Video Output. Night: 0.09 lx(XDNR ON VE ON Slow Shutter OFF 50 IRE IP)0.17 lx (Slow Shutter OFF 50 IRE Analogue Video Output
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 80 W max.
Power requirements AC 24
ONVIF conformance
IP66 Rated. Maximum environmental protection for heavy duty outdoor monitoring applications

SNC-RS44P

Internal Day/Night PTZ Dome camera, utilising state-of-the-art images enhancement and XDNR noise reduction.
1/4" CCD with Exwave HAD™ technology
Focal length f=4.1 to 73.8mm; 18X zoom ratio
Horizontal resolution 530 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Number of clients: 10
Min. illumination: Day: 0.4 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP) 0.8 lx (Slow Shutter OFF 50 IRE Analogue Video Output. Night: 0.09 lx(XDNR ON VE ON Slow Shutter OFF 50 IRE IP)0.17 lx (Slow Shutter OFF 50 IRE Analogue Video Output
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 25 W max.
Power requirements AC 24
ONVIF conformance

http://www.sonybiz.net

SNC-RS86P

Outdoor Day/Night PTZ Dome camera, utilising state-of-the-art image enhancement, 36 x optical zoom and XDNR noise reduction.
1/4" CCD with Exwave HAD™ technology
Focal length f=3.4 to 122.4mm; 36X zoom ratio
Horizontal resolution 530 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Number of clients: 10
Min. illumination: Day: 0.4 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP) 0.8 lx (Slow Shutter OFF 50 IRE Analogue Video Output. Night: 0.09 lx(XDNR ON VE ON Slow Shutter OFF 50 IRE IP)0.17 lx (Slow Shutter OFF 50 IRE Analogue Video Output
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 80 W max.
Power requirements AC 24
ONVIF conformance
IP66 Rated. Maximum environmental protection for heavy duty outdoor monitoring applications

SNC-RS46P

Internal Day/Night PTZ Dome camera, utilising state-of-the-art images enhancement and XDNR noise reduction.
1/4" CCD with Exwave HAD™ technology
Focal length f=3.4 to 122.4mm; 36X zoom ratio
Horizontal resolution 530 TV lines
XDNR noise reduction technology and VE - Visibility Enhancer - image enhancement feature
H264/MPEG-4/JPEG, 25 fps (720 x 576)
Number of clients: 10
Min. illumination: Day: 0.4 lx (XDNR ON VE ON Slow Shutter OFF 50 IRE IP) 0.8 lx (Slow Shutter OFF 50 IRE Analogue Video Output. Night: 0.09 lx(XDNR ON VE ON Slow Shutter OFF 50 IRE IP)0.17 lx (Slow Shutter OFF 50 IRE Analogue Video Output
Analogue Composite Video Output
Bi-directional Audio and Advanced audio detection
210 degree tilt angle
Serial interface RS-232C/RS-422 (PELCO D protocol)
Triple-encoding Capability
CF card x1 slot
Optional wireless
DEPA Advanced analytics
Power consumption 25 W max.
Power requirements AC 24
ONVIF conformance

http://www.sonybiz.net

SNC-RX570P

Intelligent Network Day/Night PTZ Camera with DynaView and 432x zoom- Black or White body
1/4-type CCD with Exwave HAD™ technology
Focal length f=3.4 to 122.4mm; 36X zoom ratio
Horizontal resolution 530 TV lines
Dynaview wide dynamic range technology and Dynamic frame integration
MPEG-4/JPEG - 25 fps (640 x 480); H264 - Max. 8 fps (640 x 480), 25fps (320 x 240)
Number of clients: 20
Min. illumination: Color: 1 lx (50IRE, F1.6, AGC ON), B/W: 0.15 lx (50IRE, F1.6, AGC ON)
Analogue Composite Video Output
Bi-directional Audio
Dual-encoding Capability
CF card x1 slot
Optional wireless
DEPA analytics
Power consumption 27 W max.
Power requirements AC 24V, DC 12V
Image stabilizer.

SNC-RX550P

Intelligent Network Day/Night PTZ Camera with DynaView and 312x zoom- Black or White body
1/4-type CCD with Exwave HAD™ technology
Focal length f=3.5 to 91.0mm; 26X zoom ratio
Horizontal resolution 460 TV lines
Dynaview wide dynamic range technology and Dynamic frame integration
MPEG-4/JPEG - 25 fps (640 x 480); H264 - Max. 8 fps (640 x 480), 25fps (320 x 240)
Number of clients: 20
Min. illumination: Color: 1 lx (50IRE, F1.6, AGC ON), B/W: 0.15 lx (50IRE, F1.6, AGC ON)
Analogue Composite Video Output
Bi-directional Audio
Dual-encoding Capability
CF card x1 slot
Optional wireless
DEPA analytics
Power consumption 25 W max.
Power requirements AC 24V, DC 12V
Image stabilizer

http://www.sonybiz.net

SNC-RX530P

Intelligent Network Day/Night PTZ Camera with DynaView and 216x zoom- Black or White body
1/4-type CCD with Exwave HAD™ technology
Focal length f=4.1 to 73.8mm; 18X zoom ratio
Horizontal resolution 460 TV lines
Dynamic frame integration
MPEG-4/JPEG - 25 fps (640 x 480); H264 - Max. 8 fps (640 x 480), 25fps (320 x 240)
Number of clients: 20
Min. illumination: Color: 0.7 lx (50IRE, F1.4, AGC ON), B/W: 0.15 lx (50IRE, F1.6, AGC ON)
Analogue Composite Video Output
Bi-directional Audio
Dual-encoding Capability
CF card x1 slot
Optional wireless
DEPA analytics
Power consumption 24 W max.
Power requirements AC 24V, DC 12V
Image stabilizer.

SNC-RZ25P

Pan/Tilt Zoom Network Day/Night IP Camera
1/4-type CCD with Exwave HAD™ technology
Focal length f = 4.1mm to 73.8mm; 18X zoom ratio
Horizontal resolution 460 TV lines
MPEG-4/JPEG - 25fps (320x240), 15fps (640 x 480)
Number of clients: 10 (MPEG4), 20 (JPEG)
Min. illumination: 0.7lx (50IRE, F1.4, AGC ON)
Pan angle -170 to +170 degrees
Analogue Composite Video Output
Bi-directional Audio
Dual-encoding Capability
Compact Flash™ (CF) Type Card Slot/Wireless Capability
Power consumption 17 W max.
Power requirements DC 12 V or AC 24V

http://www.sonybiz.net

info@gsc.com.ge

+995 32 2 432-432
